Table 1-16 Example for CB 540A A1/B1, CB 520X B1/B2/B3 when Onboard
LAN Card is not installed (Broadcom 1Gb 8ports)
Physical NIC
Physical Port
No.
1
Logical Port
No.
2
Detection No.
of LAN
controller
Network
segment
Mezzanine Card
1
(Broadcom 1Gb
8ports)
0 0 1 1a
1 1 1b
2 2 1c
3 3 1d
4 4 2 2a
5 5 2b
6 6 2c
7 7 2d
Mezzanine Card
3
(Broadcom 1Gb
8ports)
3
0 0 3 3a
1 1 3b
2 2 3c
3 3 3d
4 4 4 4a
5 5 4b
6 6 4c
7 7 4d
Notes:
1. The physical port number which exists on the system.
2. The logical port number which displays on the LPAR manager screen.
3. NIC cannot be installed on Mezzanine Card 3 for CB 520X B1.
LPAR manager Functions
1-27
Hitachi Compute Blade 500 Series Logical partitioning manager User's Guide
