Hitachi CP-X3030WN Overview

CP-X3030WN LCD Projector
Classroom and
Conference Room
Series
PC-Less Presentation
By using a USB memory stick or other storage device, you can
use the projector without a computer. Menus are easy to see
with a thumbnail display. There is also a slideshow function. This
feature also supports the following file types: JPG, PNG, BMP,
GIF, AVI, and MOV — frame rate is under 12fps 640 x 480.
PIN Lock / MyScreen / MyText
PIN lock protection can limit projector users. MyScreen PIN
lock keeps captured images on the startup screen. Users can
set any name logo to MyScreen, clearly identifying ownership.
MyText provides the ability to write text on the startup screen
such as model name, serial number or location.
PJMessenger
PJMessenger function allows you to send and display text
messages and audio alerts on your networked projectors. It
is an easy and efficient way to send announcements out to
multiple units.
Present Content via LAN
Hitachi’s suite of networking software allows you to easily
send content directly from your PC to the projector via your
LAN connection.
Serial Number and Media Access Control Label
A label is affixed to side of projector to more easily access
and read the model name, serial number and MAC address
while mounted in ceiling use. This is a convenience for
installers, end users and auditors for instant accessibility.
Serial #
Wireless Presentation Ready
You can use a wireless network by connecting the projector
to a computer using the optional USB wireless adapter part
number USBWL11N. The adapter supports IEEE802.11b/g
and the latest 11n.
Hitachi America, Ltd.
900 Hitachi Way, Chula Vista, CA 91914
Toll Free: 1.800.HITACHI
•
Email: dmd.info@hal.hitachi.com
Web: hitachi-america.us/projectors
HI0159 Rev.2-05/13 WEB
All specifications subject to change without notice.
3LCD and the 3LCD logo are registered trademarks of the Seiko Epson Corporation.
©2013 Hitachi America, Ltd. All Rights Reserved .
* Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings
and usage. Hours of average filter life specified are not guaranteed and do not constitute part of the product warranty.
** Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user
settings and usage. Hours of average lamp life specified are not guaranteed and do not constitute part of the product or
lamp warranty. Lamp brightness decreases over time.
STANDARD FEATURES
UNIQUE FEATURES
Display via USB
Simply plug and play using the USB port instead of the
15-pin D-sub VGA cable.
Network Control, Maintenance and
Security
Embedded networking gives you the ability
to manage and control multiple projectors
over your LAN. Features include scheduling
of events, centralized reporting, image
transfer and e-mail alerts for reactive and
routine maintenance.
Cloning Function
Copy configuration settings from one projector to others of the
same model via USB memory. Cloning can save almost all PJ
settings such as gamma and keystone via USB memory.
settings
settings
Intelligent Eco and Saver Modes
Automatically changes the brightness of the lamp according to
the brightness level of the screen. Also, automatically changes
the brightness of the lamp if there is no change in the screen
image. Using ImageCare technology, these features give
optimal picture performance with maximum energy savings.
Input Source Naming
Users can name input sources in simple language instead of
factory default name. Exclusive to Hitachi.
Microphone Input
A microphone can be used via the jack located on the
input panel. Allows for more dynamic presentations even in
standby mode.
ImageCare Technology
ImageCare is a lamp power control function that combines
optimal picture performance with maximum energy savings
by decreasing energy usage, improving contrast ratio and
lengthening lamp life. The result is a lower total cost of
ownership and decreased maintenance cost.
Drawing Function with Optional Tablet (TB-1)
The optional Hitachi wireless tablet and pen allows you to
engage your audience by annotating over images shown on
the projector.

Hitachi CP-X3030WN Specifications

General

Number of colors	16.78 million colors
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	4:3, 16:9, 16:10
Contrast ratio (typical)	4000:1
Screen size compatibility	30 - 300 \
Projection distance (tele)	1 - 10.8 m
Projection distance (wide)	0.8 - 9 m
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-30 - 30 °
Horizontal synchronization (max)	106 kHz
Horizontal synchronization (min)	31.5 kHz
Projector brightness (economic mode)	2100 ANSI lumens
Focus	Manual
Zoom capability	Yes
Focal length range	- mm
Lamp type	UHP
Lamp power	215 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	6000 h
Full HD	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
RMS rated power	16 W
Number of built-in speakers	1
Built-in display	-
HDMI version	1.4
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	3
Noise level	38 dB
Certification	UL60950-1/cUL, FCC Part 15 subpart B class B, CE Marking: EN61000-3-2, EN61000-3-3, EN55022, EN55024 (EMC Directive), EN60950-1 (Low voltage directive), WEEE, RoHS, ErP (lot6) compliant, c-tick class B
Noise level (economic mode)	30 dB
Placement	Desktop
Product type	Standard throw projector
Product color	White
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	310 W

Weight and Dimensions

Depth	245 mm
Width	320 mm
Height	85 mm
Weight	3000 g
