1.10 COMPATIBLE DEVICES
1.10.1 KNX001 Compatibility
A HITACHI Air-Conditioning system can be integrated with a KNX system by using CSNET Manager and the KNX001 device:
EIB
KNX
ETHERNET
CSNET Manager LT/XT
(Master)
ETHERNET
HC-A64NET
HC-A64NET
KNX001
H-LINK
H-LINK
RS-232
2QO\GXULQJFRQ¿JXUDWLRQ
.1;FRPPXQLFDWHVWKURXJK0RGEXV7&3ZLWK&61(70DQDJHUZKHUH0RGEXVVHUYHURSWLRQPXVWEHFRQ¿JXUHGDQGUXQQLQJ
$IWHUWKDW.1;SHUIRUPVFRQWLQXRXVSROOLQJUHDGLQJRIDOOWKHVLJQDOVFRQ¿JXUHGLQ&61(70DQDJHUDQGNHHSVWKHLUVWDWXV
updated in order to serve as information to the KNX system.
CSNET Manager is compatible with KNX001 with some restrictions.
System is 100% compatible when CSNET Manager has only 1 HC-A64NET.
KNX001
64 IU
General characteristics
