Hitachi DS 18DSFL - DS 18 DSFL Model Specifications

-4-
Model
Item
DS 18DSFL
Capacity
Screw driving Machine screw ------------ 6 mm (1/4")
Wood screw
--------------- 6.8 mm dia. x 50 mm (#16 x 2")
Drilling Metal
------- Mild steel --- 13 mm (1/2") [Thickness 1.6 mm (1/16")]
Wood
----------------------- 38 mm (1-1/2") [Thickness 18 mm (11/16")]
Keyless chuck
(13VLRS-N)
Mount type ----------------------Screw-on (1/2" - 20 UNF)
Diameter
-------------------------2.0 to 13 mm (5/64" to 1/2")
Rotation speed
(No-load)
Low: 0 to 450 min
-1
, High: 0 to 1,250 min
-1
Torque
Slip torque-----------------------1 to 6.0 N•m (10 to 60 kgf•cm, 9 to 52 in-lbs.) [22 stages]
Max. torque
---------------------Low: 41 N•m (418 kgf•cm, 364 in-lbs.)
High: 10 N
•m (101 kgf•cm, 88.7 in-lbs.)
Type of motor Fan-cooled DC magnet motor
Type of switch
Trigger switch with pushing button for forward and reverse rotation changeover
(with brake)
Enclosure
Body -----------------------------Glassfiber-reinforced polyamide resin (black)
and thermoplastic elastomer (green)
Battery --------------------------Polycarbonate resin (black)
Charger
-------------------------ABS resin (black)
Battery
(Type BSL 1815)
Sealed cylindrical lithium-ion storage battery
Nominal voltage
----------------DC 18 V
Nominal life
---------------------Charging/discharging: Approx. 1,000 times
Nominal capacity
---------------1.5 Ah
Charger
(Model UC 18YGSL)
Overcharge protection system:
(1) Battery surface temperature detection (by thermostat or thermistor)
(2) Stop current detection
Power input: 60 W
Charging time: Approx. 40 minutes [for Type BSL 1815 Battery at 20°C (68°F)]
Operable ambient temperature range: 0
°C to 50°C (32°F to 122°F)
The maximum allowable temperature of the Type BSL 1815 Battery is 50
°C (122°F).
Indication method of battery charging function
Net
Main body unit (including battery) ------------------------------------------- 1.7 kg (3.7 lbs.)
Charger unit (UC 18YGSL, including cord)
--------------------------------- 0.4 kg (0.9 lb.)
Weight
Gross
DS 18DSFL (2LEGK) - -------------------------------------------------------- 4.2 kg (9.3 lbs.)
Standard
accessories
2LEGK
• Charger (UC 18YGSL) ------------------------------------------------------ 1
• Battery (BSL 1815) ---------------------------------------------------------- 2
• Phillips (plus) driver bit (No. 2) --------------------------------------------- 1
• Case --------------------------------------------------------------------------- 1
