PARTS DS 18DSAL
DESCRIPTION REMARKS
* 1 311-959 SPECIAL SCREW (LEFT HAND) M6X23 1 (LEFT HAND)
* 1 330-588 SPECIAL SCREW (LEFT HAND) M6X27 1 (LEFT HAND) FOR USA, CAN
* 2 330-586
DRILL CHUCK 13VLRQ-N (W/O CHUCK WRENCH) 1
* 2 330-587
DRILL CHUCK 13VLRP-N (W/O CHUCK WRENCH) 1 FOR USA, CAN
3 330-559 GEAR BOX ASS'Y 1 INCLUD. 4-28
4 330-582 CLUTCH DIAL 1
5 330-563 NUT 1
6 330-562 SPRING 1
7 330-561 THRUST PLATE 1
8 331-090 FRONT CASE 1
9 331-089 CLICK SPRING 1
10 306-936 STEEL BALL D5 6
11 331-088 LOCK RING (A) 1
12 330-565 NEEDLE ROLLER SET (6 PCS.) 6
13 330-567 RING GEAR 1
14 330-566 CARRIER 1
15 330-568 PLANET GEAR (C) SET (4 PCS.) 4
16 330-569 PLATE (B) 1
17 330-570 REAR CASE 1
18 330-579 SCREW SET D2X3.5 (2 PCS.) 2
19 312-712 SCREW SET D3X12 (4 PCS.) 4
20 330-580 SHIFT ARM 1
21 330-572 SLIDE RING GEAR 1
22 330-571 PINION (C) 1
23 330-573 PLANET GEAR (B) SET (3 PCS.) 3
24 330-574 PINION (B) 1
25 330-576 PLANET GEAR (A) SET (3 PCS.) 3
26 330-575 FIRST RING GEAR 1
27 330-577 PLATE (A) 1
28 330-578 MOTOR SPACER 1
29 360-866 ARMATURE AND PINION SET 1
30 322-520 MAGNET 1
31 322-521 DUST GUARD 1
32 322-993 BRUSH BLOCK 1
33 999-054 CARBON BRUSH 5X6X11.5 (1 PAIR) 2
34 319-918 BRUSH CAP 2
35 313-687
TAPPING SCREW (W/FLANGE) D3X16 (BLACK) 8
36 330-594 HOUSING (A).(B) SET 1
37 330-583 SHIFT KNOB 1
38 330-596 DC-SPEED CONTROL SWITCH 1
39 329-454 PUSHING BUTTON (A) 1
40 330-584 LED HOLDER 1
41 327-001 TRUSS HD. SCREW M4 (BLACK) 1
42 329-686 HOOK (A) 1
43 306-952 STRAP (BLACK) 1
44 327-002 LOCK NUT M4 (BLACK) 2
45 327-004 PACKING 2
46 330-591 CONTROLLER TERMINAL SET 1
47 NAME PLATE 1
* 48 330-068 BATTERY BSL 1830 (EUROPE, AUS, NZL) 2
- 2 - 1 - 09
*ALTERNATIVE PARTS
