Hitachi DSP-110A6N User Manual

Model DSP-90W6N DSP-110W6N DSP-90VW6N DSP-110VW6N
Air Compressor
Discharge Pressure psi (MPa)
100
(0.69)
125
(0.86)
100
(0.69)
125
(0.86)
100
(0.69)
125
(0.86)
100
(0.69)
125
(0.86)
Intake air Press./Temp.
℉(℃)
Atmospheric Pressure, 32 to 104 (0 to 40)
Type of compressed gas − Air
Capacity@rated
pressure 60Hz
cfm (m
3
/
min)
646/551
(18.3/15.6)
742/622
(21.0/17.6)
646/551
(18.3/15.6)
742/622
(21.0/17.6)
Maximum motor
shaft power
HP (kW) 160 (120) 185 (138) 160 (120) 185 (138)
No. of Compression Stage − 2-Stage
Driving Method − Gear Driven
Motor Starting Method − Star-Delta Inverter
Discharge Air Pipe Connection inch 2 (flange connection)
Discharge Air Temperature
℉(℃)
Cooling Water Temperature +23(13), or less
Cooling Water Pipe Connection inch 1-1/2
Cooling Water inlet Temperature
℉(℃)
95(35) or less
Cooling Water Quantity gpm (L /min) 42 (160) 48 (180) 42 (160) 48 (180)
Oil Quantity gal (L) 4.2 (16) (Not filled)
Capacity Control System − On-Off line, 0% or 100% capacity, 2-step Variable Speed + Purge + Auto stop/restart
Oil Cooler −
Water cooled Horizontal Shell and Tube Type
(Water passes inside of Tubes)
I ntercooler/
Aftercooler
−
Water cooled Horizontal Shell and Tube Type
(Water passes outside of Tubes)
Main Motor
Nominal Output HP (kW) 135 (100) 160 (120) 135 (100) 160 (120)
Type − Totally Enclosed Motor
Voltage A 460
Rated Current A 150 175 150 175
Frequency Hz 60
Number of Pole −2
Insulation Class −F
Cooling Fan Motor
Nominal Output HP(kW) 0.067×3 (0.05×3) 0.268×2 (0.2×2)
Type − − PN-404-02H
Voltage V 460
Maximum Current A 0.4 0.6
Frequency Hz 60
Number of Pole −4
Insulation Class −E
Approximate Weight lbs (kg) 5,030 (2,280) 5,380 (2,440) 5,250 (2,380) 5,360 (2,430)
External Dimensions
(W×D×H)
inches
(mm)
84.6×59.8×71.9
(2,150×1,520×1,825)
NOTE: (1) Capacity is measured according to ISO 1217, Third Edition, Annex C.
(2) Earth leakage circuit breaker is out of scope of supply from Hitachi.
(3) DSP series air compressors are not designed, intended or approved for breathing air applications.
(4) Pressures are indicated as the gauge pressure.
(5) Install the air compressor indoors and avoid flammable and corrosive environment, moisture and dust.
(6) Use 3.5-4.5 ton duty fork truck for transportation of this air compressor.
(7) Hitachi may make improvements and/or changes in the appearance and/or specifications described in this publication at
anytime without notice.
123
15. STANDARD SPECIFICATIONS
Water-Cooled

Hitachi DSP-110A6N Specifications

General

Brand	Hitachi
Model	DSP-110A6N
Category	Air Compressor
Language	English
