Number Description
• Hard drive
•
System standby power
2
Reset button.
3
Power button. Applies power to or removes
power from the SVP.
SVP rear panel
The only ports used on the rear panel of the SVP are the power sock
et and
the four LAN ports.
Number Description
1
Power socket. Attach the power cable supplied
with the SVP
.
2
Four LAN ports arranged as follows:
LAN3 LAN4
LAN1 LAN2
These ports connect to your IP network, the
management console PC, and the user LAN port
on each storage system controller.
SVP hardware specifications
The following table lists the SVP hardw
are specifications.
Item Specification
Dimensions Height: 1.7 inches (43 mm)
Width: 17.2 inches (437 mm)
Depth: 14.5 inches (369 mm)
W
eight: 14 lbs (6.4 kg)
Processor Celeron G1820 2.7 GHz 2M, 2C, 2T
Overview 17
Hitachi Virtual Storage Platform G200, G400, G600 Service Processor Technical Reference
