• Local Storage System on page B-35
• Remote Storage System on page B-35
• Remote Paths on page B-35
Local Storage System
Item Description
Model Local system model.
Serial Number Local system serial number.
Remote Storage System
Item Description
Model Remote system model.
Serial Number Remote system serial number.
Remote Paths
Item Description
Path Group ID Path group identifier. A hyphen (-) is displayed for CU
connection.
Minimum Number of Paths Specified minimum number of remote paths.
Total Number of Paths Displays the total number of path registered to remote
connection and path to be added (includes blank line).
Select Type Select the port type.
• Fibre
• iSCSI
Port ID (local storage
system)
Displays the port ID of the local storage system.
Port ID (remote storage
system)
Displays the port ID of the remote storage system.
IP Address Displays the port's IP address of the remote storage
system.
Only displays when selecting iSCSI for Select Type.
TCP Port Number Displays the TCP port number of the remote storage
system.
Only displays when selecting iSCSI for Select Type.
Remove Check box for deleting the path from the remote
connection.
TC GUI reference
B-35
Hitachi TrueCopy® User Guide for Hitachi Virtual Storage Platform Gx00 and Fx00 Models
