Systems Insight Display LEDs
Description Status
Processor LEDs
Off = Normal
Amber = Failed processor
DIMM LEDs
Off = Normal
Amber = Failed DIMM or configuration issue
DIMM group LEDs
Off = Normal
Amber = Failed DIMM or configuration issue
Fan LEDs
Off = Normal
Amber = Failed fan or missing fan
NIC LEDs
1
Off = No link to network
Solid green = Network link
Flashing green = Network link with activity
If power is off, the front panel LED is not active. For
status, see Rear panel LEDs.
Power supply LEDs
Off = Normal
Solid amber = Power subsystem degraded, power
supply failure, or input power lost.
PCI riser LED
Off = Normal
Amber = Incorrectly installed PCI riser cage
Over temp LED
Off = Normal
Amber = High system temperature detected
Power cap LED
Off = System is in standby, or no cap is set.
Solid green = Power cap applied
Amp Status LED
Off = AMP modes disabled
Solid green = AMP mode enabled
Solid amber = Failover
Flashing amber = Invalid configuration
1
Embedded NIC ports are not equipped on the server. NIC LEDs on the Systems Insight Display will flash based on the
network adapter port activity. In the case of a dual-port adapters, only NIC LED 1 and 2 will illuminate to correspond with
the activity of the respective network ports.
