Chapter 4 Explanation of Functions
4 - 143
Register
No.
Function name Function code R/W
Monitoring and setting items Data
resolution
Register
No.
1633h Motor poles setting for RPM P049 R/W
0 (0 pole), 1 (2 poles), 2 (4 poles), 3 (6
poles), 4 (8 poles), 5 (10 poles), 6 (12
poles), 7 (14 poles), 8 (16 poles), 9 (18
poles), 10 (20 poles), 11 (22 poles), 12
(24 poles), 13 (26 poles), 14 (28 poles),
15 (30 poles), 16 (32 poles), 17 (34
poles), 18 (36 poles), 19 (38 poles)
-
1634h to
1638h
(Reserved) - - Inaccessible -
1639h Pulse train frequency scale P055 R/W
10 to 500 (input frequency corresponding
to the allowable maximum frequency)
0.1 [kHz]
163Ah
Time constant of pulse train frequency
filter
P056 R/W 1 to 200 0.01 [sec.]
163Bh Pulse train frequency bias P057 R/W -100 to +100 1 [%]
163Ch Pulse train frequency limit P058 R/W 0 to 100 1 [%]
163Dh (Reserved) - - Inaccessible -
1656h to
1665h
(Reserved) - - Inaccessible -
1666h Easy sequence user parameter U (00) P100 R/W 0 to 65530 1
1667h Easy sequence user parameter U (01) P101 R/W 0 to65530 1
1668h Easy sequence user parameter U (02) P102 R/W 0 to 65530 1
1669h Easy sequence user parameter U (03) P103 R/W 0 to 65530 1
166Ah Easy sequence user parameter U (04) P104 R/W 0 to 65530 1
166Bh Easy sequence user parameter U (05) P105 R/W 0 to 65530 1
166Ch Easy sequence user parameter U (06) P106 R/W 0 to 65530 1
166Dh Easy sequence user parameter U (07) P107 R/W 0 to 65530 1
166Eh Easy sequence user parameter U (08) P108 R/W 0 to 65530 1
166Fh Easy sequence user parameter U (09) P109 R/W 0 to 65530 1
1670h Easy sequence user parameter U (10) P110 R/W 0 to 65530 1
1671h Easy sequence user parameter U (11) P111 R/W 0 to 65530 1
1672h Easy sequence user parameter U (12) P112 R/W 0 to 65530 1
1673h Easy sequence user parameter U (13) P113 R/W 0 to 65530 1
1674h Easy sequence user parameter U (14) P114 R/W 0 to 65530 1
1675h Easy sequence user parameter U (15) P115 R/W 0 to 65530 1
1676h Easy sequence user parameter U (16) P116 R/W 0 to 65530 1
1677h Easy sequence user parameter U (17) P117 R/W 0 to 65530 1
1678h Easy sequence user parameter U (18) P118 R/W 0 to 65530 1
1679h Easy sequence user parameter U (19) P119 R/W 0 to 65530 1
167Ah Easy sequence user parameter U (20) P120 R/W 0 to 65530 1
167Bh Easy sequence user parameter U (21) P121 R/W 0 to 65530 1
167Ch Easy sequence user parameter U (22) P122 R/W 0 to 65530 1
167Dh Easy sequence user parameter U (23) P123 R/W 0 to 65530 1
167Eh Easy sequence user parameter U (24) P124 R/W 0 to 65530 1
167Fh Easy sequence user parameter U (25) P125 R/W 0 to 65530 1
1681h Easy sequence user parameter U (27) P127 R/W 0 to 65530 1
1682h Easy sequence user parameter U (28) P128 R/W 0 to 65530 1
1683h Easy sequence user parameter U (29) P129 R/W 0 to 65530 1
1684h Easy sequence user parameter U (30) P130 R/W 0 to 65530 1
1685h Easy sequence user parameter U (31) P131 R/W 0 to 65530 1
1686h to
2102h
(Reserved) - - Inaccessible -
*1 The following table lists the code data for parameter "H003" (motor capacity selection):
Code data 00 01 02 03 04 05 06 07 08 09 10
Motor capacity 0.2 kW - 0.4 - 0.75 - 1.5 2.2 - 3.7 -
Code data 11 12 13 14 15 16 17 18 19 20 21
Motor capacity 5.5 kW 7.5 11 15 18.5 22 30 37 45 55 75
Code data 22 23 24 25 26
Motor capacity 90kW 110 132 150 160
