Communication settings
89
1st Layer 2nd Layer 3rd Layer 4th Layer Selections
Hitachi Commands
Operation
Header Data (7 bytes) Command Data (6 bytes)
Description
Header
Code
Packet
Data
Size
CRC Action Type
Setting
Code
Color
Manager
Blue
Hue 0~100
Set 0 - 100 BE EF 03 06 00 [*1] 01 00 04 27 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 64
00 (Max)
Increment BE EF 03 06 00 5A 62 04 00 04 27 00 00
Decrement BE EF 03 06 00 8B 63 05 00 04 27 00 00
Get BE EF 03 06 00 3C 62 02 00 04 27 00 00
Saturation 0~100
Set 0 - 100 BE EF 03 06 00 [*1] 01 00 14 27 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 64
00 (Max)
Increment BE EF 03 06 00 9A 66 04 00 14 27 00 00
Decrement BE EF 03 06 00 4B 67 05 00 14 27 00 00
Get BE EF 03 06 00 FC 66 02 00 14 27 00 00
Gain 0~100
Set 0 - 100 BE EF 03 06 00 [*1] 01 00 24 27 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 64
00 (Max)
Increment BE EF 03 06 00 9A 69 04 00 24 27 00 00
Decrement BE EF 03 06 00 4B 68 05 00 24 27 00 00
Get BE EF 03 06 00 FC 69 02 00 24 27 00 00
Cyan
Hue 0~100
Set 0 - 100 BE EF 03 06 00 [*1] 01 00 03 27 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 64
00 (Max)
Increment BE EF 03 06 00 2E 63 04 00 03 27 00 00
Decrement BE EF 03 06 00 FF 62 05 00 03 27 00 00
Get BE EF 03 06 00 48 63 02 00 03 27 00 00
Saturation 0~100
Set 0 - 100 BE EF 03 06 00 [*1] 01 00 13 27 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 64
00 (Max)
Increment BE EF 03 06 00 EE 67 04 00 13 27 00 00
Decrement BE EF 03 06 00 3F 66 05 00 13 27 00 00
Get BE EF 03 06 00 88 67 02 00 13 27 00 00
Gain 0~100
Set 0 - 100 BE EF 03 06 00 [*1] 01 00 23 27 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 64
00 (Max)
Increment BE EF 03 06 00 EE 68 04 00 23 27 00 00
Decrement BE EF 03 06 00 3F 69 05 00 23 27 00 00
Get BE EF 03 06 00 88 68 02 00 23 27 00 00
Magenta
Hue 0~100
Set 0 - 100 BE EF 03 06 00 [*1] 01 00 05 27 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 64
00 (Max)
Increment BE EF 03 06 00 A6 63 04 00 05 27 00 00
Decrement BE EF 03 06 00 77 62 05 00 05 27 00 00
Get BE EF 03 06 00 C0 63 02 00 05 27 00 00
Saturation 0~100
Set 0 - 100 BE EF 03 06 00 [*1] 01 00 15 27 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 64
00 (Max)
Increment BE EF 03 06 00 66 67 04 00 15 27 00 00
Decrement BE EF 03 06 00 B7 66 05 00 15 27 00 00
Get BE EF 03 06 00 00 67 02 00 15 27 00 00
Gain 0~100
Set 0 - 100 BE EF 03 06 00 [*1] 01 00 25 27 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 64
00 (Max)
Increment BE EF 03 06 00 66 68 04 00 25 27 00 00
Decrement BE EF 03 06 00 B7 69 05 00 25 27 00 00
Get BE EF 03 06 00 00 68 02 00 25 27 00 00
Yellow
Hue 0~100
Set 0 - 100 BE EF 03 06 00 [*1] 01 00 01 27 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 64
00 (Max)
Increment BE EF 03 06 00 96 62 04 00 01 27 00 00
Decrement BE EF 03 06 00 47 63 05 00 01 27 00 00
Get BE EF 03 06 00 F0 62 02 00 01 27 00 00
Saturation 0~100
Set 0 - 100 BE EF 03 06 00 [*1] 01 00 11 27 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 64
00 (Max)
Increment BE EF 03 06 00 56 66 04 00 11 27 00 00
Decrement BE EF 03 06 00 87 67 05 00 11 27 00 00
Get BE EF 03 06 00 30 66 02 00 11 27 00 00
Gain 0~100
Set 0 - 100 BE EF 03 06 00 [*1] 01 00 21 27 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 64
00 (Max)
Increment BE EF 03 06 00 56 69 04 00 21 27 00 00
Decrement BE EF 03 06 00 87 68 05 00 21 27 00 00
Get BE EF 03 06 00 30 69 02 00 21 27 00 00
White
Red 0~100
Set 0 - 100 BE EF 03 06 00 [*1] 01 00 28 27 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 64
00 (Max)
Increment BE EF 03 06 00 CA 6A 04 00 28 27 00 00
Decrement BE EF 03 06 00 1B 6B 05 00 28 27 00 00
Get BE EF 03 06 00 AC 6A 02 00 28 27 00 00
Green 0~100
Set 0 - 100 BE EF 03 06 00 [*1] 01 00 2A 27 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 64
00 (Max)
Increment BE EF 03 06 00 72 6B 04 00 2A 27 00 00
Decrement BE EF 03 06 00 A3 6A 05 00 2A 27 00 00
Get BE EF 03 06 00 14 6B 02 00 2A 27 00 00
Blue 0~100
Set 0 - 100 BE EF 03 06 00 [*1] 01 00 2C 27 [*2]
[*1]: CRC (Low, High)
[*2]: 00 00 (Min) - 64
00 (Max)
Increment BE EF 03 06 00 FA 6B 04 00 2C 27 00 00
Decrement BE EF 03 06 00 2B 6A 05 00 2C 27 00 00
Get BE EF 03 06 00 9C 6B 02 00 2C 27 00 00
Settings 1
Source
HDMI 1
Set
HDMI 1 BE EF 03 06 00 0E D2 01 00 00 20 03 00
HDMI 2 / MHL HDMI 2 / MHL BE EF 03 06 00 6E D6 01 00 00 20 0D 00
DVI DVI-D BE EF 03 06 00 AE D4 01 00 00 20 09 00
VGA Computer in 1 BE EF 03 06 00 FE D2 01 00 00 20 00 00
BNC Computer in 2 BE EF 03 06 00 3E D0 01 00 00 20 04 00
Composite Video Video BE EF 03 06 00 6E D3 01 00 00 20 01 00
HDBaseT HDBaseT BE EF 03 06 00 AE DE 01 00 00 20 11 00
Get BE EF 03 06 00 CD D2 02 00 00 20 00 00
Projection
Normal / Front
Set
Front Tabletop BE EF 03 06 00 C7 D2 01 00 01 30 00 00
Rear Rear Tabletop BE EF 03 06 00 57 D3 01 00 01 30 01 00
Ceiling Front Ceiling BE EF 03 06 00 37 D2 01 00 01 30 03 00
Rear + Ceiling Rear Ceiling BE EF 03 06 00 A7 D3 01 00 01 30 02 00
Get BE EF 03 06 00 F4 D2 02 00 01 30 00 00
Aspect Ratio
Fill
Set
16:10 BE EF 03 06 00 3E D6 01 00 08 20 0A 00
4:3 4:3 BE EF 03 06 00 9E D0 01 00 08 20 00 00
16:9 16:9 BE EF 03 06 00 0E D1 01 00 08 20 01 00
Letter Box Letter Box BE EF 03 6 00 3E D3 01 00 08 20 06 00 Movie-1
Native Native BE EF 03 6 00 5E D7 01 00 08 20 08 00
2.35:1 2.35:1 BE EF 03 6 00 0E D4 01 00 08 20 0D 00
Get BE EF 03 06 00 AD D0 02 00 08 20 00 00
