Hitachi RCI - RPI - Ducted Indoor Unit; Removal of the Electrical Box

10.4 RPI - Ducted indoor unit
10.4.1 Removal of the electrical box
Nº Part
1 Location of the electrical box cover
N O T E
• The figures show the service procedures for the RPI-(0.8–
1.5)FSN2E. model.
• The service procedures for the RPI-(2.0–6.0)FSN2E models
are the same.
Remove the electrical box cover to access the electrical
components.
Nº
Part
1 Electrical box cover
2 Electrical box
Remove the set screws and remove the electrical box from the unit.
