Hitachi America, Ltd. RCU SERIES
`
2.5 Mounting
The RCU should be mounted in a vertical position on the wall or on the back plane of a
cubicle. Follow the requirement for cooling. See chapter 3.2 for dimensions.
In order to ensure a safe installation, make sure that the mounting surface is relatively flat.
Fixing is done with four or more screws or bolts depending on the size of the unit. See Figure
2.5-1 ~ 2.5-3.
2.5.1 KE2
Figure 2.5-1 KE2 Mounting dimension
