RESET FAULT USING INPUT
Resetting a fault remotely using an input to the VFD can be done by configuring one of the available digital inputs for reset. Use the
chart below.
Function
Parameters
Value
Fault reset C006 – C007 18 = RS
OUTPUT SIGNAL WHEN FAULT OCCURS
You can configure a 24v digital output to turn on when a fault occurs. If the VFD is configured for hoisting, then you will need to
configure the over-weight logic for either maintained or internal in order to free up digital output 12. If you need to change the over-
weight logic, please reference the hoist over-weight function section to change the logic to maintained or internal.
Function
Parameters
Value
Output 12 Function C022 05 = Faut / Alarm
Output 12 Contact Status C032
00 = N.O
01 = N.C
Output 12 On-Delay Time C132 0.0 – 100.0 s
Output 12 Off-Delay Time C133 0.0 – 100.0 s
ELECTRONIC MOTOR THERMAL PROTECTION
The VFD has a built-in electronic motor thermal protection function and is configured for constant torque loading. When the output
current exceeds the value in b012 for a calculated time based on frequency and time the VFD will trip with an E05 fault.
Function
Parameters
Value
Electronic thermal level b012 Motor FLA * 1.25
