1-29
OPERATOR'S STATION
MDC1-01-519EN
MDC1-01-520EN
Engine Output Restriction Suspend
When a lack of DEF/AdBlue® or Urea SCR system malfunction
occurs, alarm mark (1) will be displayed on the basic screen
and engine output / speed will be limited.
IMPORTANT:
This function can be performed only one time at one
engine output limit.
This is only a temporary release operation. Refill
DEF/AdBlue® or repair Urea SCR system as soon as
possible. Consult your authorized dealer to repair
the system.
The engine output limit function can be temporarily released
when evacuation is unavoidable during machine operation.
Follow the below procedure.
1. Push selector knob (2) on the Basic Screen to display
Main Menu (3).
2. Rotate selector knob (2) to highlight Engine Output
Restriction Suspend (4).
f
NOTE: Engine output restriction suspend (4) is displayed
on main menu (3) only when the engine output and speed is
restricted.
2
3
4
MDCD-01-026
1
MDC1-01-521EN
To Next Page
