Hitron CODA-551x User’s Guide
Channel Bandwidth Use this field to configure the width of the radio channel
the CODA-551x uses to communicate with its wireless
clients (IEEE 802.11n only) on the 2.4GHz network.
Using the full 40MHz bandwidth can double your data
speed.
Select 20 MHz to only use a 20 megahertz band.
Select 20/40 MHz to use a 40 megahertz band
when possible, and a 20 megahertz band when a
40 megahertz band is unavailable.
Wireless Channel Select the 2.4GHz wireless channel that you want to
use, or select Auto to have the CODA-551x select the
optimum channel to use.
NOTE: Use the Auto setting unless you have a specific
reason to do otherwise.
Click the Refresh button ( ) to have the CODA-551x
recheck the current wireless network conditions and
select the optimum 2.4GHz wireless channel afresh
(see Automatic Channel Selection on page 77
).
WPS Enabled Use this field to turn Wifi Protected Setup (WPS) on or
off on the 2.4GHz network (see WPS on page 80).
Select ON to enable WPS.
Select OFF to disable WPS.
Multiple SSID Settings
Network Name (SSID) Enter the name that you want to use for this SSID. This
is the name that identifies your network, and to which
wireless clients connect.
NOTE: It is suggested that you change the SSID from
its default, for security reasons.
Enable Use this field to enable or disable the SSID.
Select ON to enable the SSID.
Select OFF to disable the SSID.
Table 23: The Wireless: Basic Settings: 2.4G Screen (continued)
