HK Audio Cohedra User Manual

Manual
COHEDRA
®
& COHEDRA
®
Compact
Preface
This manual is addressed to all technicians who are responsible for setting up, operating and maintaining
the HK Audio® Cohedra™ Compact system. In addition, we would like to explain in detail the principles and
functions of HK Audio® Cohedra™ technology to all interested planning and installation engineers.
Content
A Die COHEDRA
®
Technology .....................................5
B COHEDRA
®
Enclosures ...........................................10
B 1 COHEDRA
®
Compact Enclosures .........................14
C COHEDRA
®
Transport Solution ...........................17
C 1 COHEDRA
®
Compact Transport Solution ..........20
D Rigging and Curving COHEDRA
®
Systems .........22
D 1 Rigging and Curving COHEDRA
®
Compact ........36
E COHEDRA
®
Setups with CAPS .................................48
F COHEDRA
®
Controlling Concept ........................61
G Controller and Controller Software ...............63
H COHEDRA
®
Power-Racks ..........................................81
I Power Amp VX 2400 ...................................................85
J Patchbay PB5 ..............................................................90
K Service COHEDRA
®
....................................................95
K 1 Service COHEDRA
®
Compact ...................................98
L Appendix/Reference library .................................100
co_coco_BDA_de_engl_2.indd 4 18.09.2006 17:08:48

HK Audio Cohedra Specifications

General

Brand	HK Audio
Model	Cohedra
Category	Stereo System
Language	English
