HK Audio L.U.C.A.S MAX User Manual

Service Documents
TECHNICAL SERVICE:
Stamer Musikanlagen GmbH • Magdeburger Str. 8 • 66606 St.Wendel • Germany
Music & Sales P.E. GmbH • Leipziger Str. 3 • 66606 St.Wendel • Germany
L.U.C.A.S Max Subwoofer
Inputs/outputs:
Line In: XLR female (pin 1= ground; 2= +, 3= -)
Input: Electronically balanced & floating
Input impedance: 47 k ohms
Sensitivity: +4 dBu
Max. input level: + 19 dBu
Parallel out: XLR male (pin 1= ground; 2=+, 3= -)
Speaker outputs: Speakon
®
NL 4 (pin 1+= +, 1-= -)
Digital controller:
Sampling frequency: 24 bits/ 48 kHz
Internal signal processing: 56 bits
Amplifiers:
Subwoofer output: 1x 1000 W @ 4 ohms RMS /
Class D power amp
Satellites output: 2x 500 W RMS @ 8 ohms RMS /
Class D power amp
Protective circuits: DDO™ controlled multi-band limiter
Speakers:
Woofer: 1x 15" Neodymium
Subwoofer frequency response: 40 Hz -130 Hz, ± 3 dB
32 Hz -130 Hz, - 10 dB
SPL 1W / 1m: 101 dB (half space)
Max. SPL / 1m: 130 dB @ 10% THD (half space)
Weights and measures:
Weight: 39 kg / 86 lbs.
Dimensions without casters 48.5 cm x 49.5 cm x 58.5 cm
(WxHxD): 19 " x 19 1/2" x 23"
L.U.C.A.S Max Satellite
Inputs:
Speaker input: Speakon NL 4 (pin 1+= +, 1-= -)
Speakers:
Woofer: 1x 10" Neodymium
Driver: 1x 1"
Directivity: 60°x 40° CD horn
Nominal impedance: 8 ohms
Nominal power handling: 250 W RMS fullrange
400 W RMS (130 Hz Low Cut)
SPL 1W / 1m: 104 dB (half space)
Max. SPL / 1m: 126 dB @ 10% THD (half space)
Frequency response: 130 Hz - 19 kHz, +/- 3 dB
(via DDO™Controller)
Crossover frequency (passive): 2.2 kHz, 12 dB / octave
Driver protection: Dynamic protective circuit
Pole mount: HK Audio DuoTilt™ 36 mm, -7.5° und –15°
Weights and measures:
Weight: 11 kg / 24.3 lbs.
Dimensions (WxHxD): 31.5 cm x 49 cm x 32 cm
12 3/8" x 19 1/3" x 12 5/8"
General electrical data:
Protection class 1 (protectively earthed)
Max. current consumption: 8.6 A (220 - 240 V) • 15 A (100 - 120 V)
Max. power consumption: 2000 W
Mains voltage range +/- 10%
Ambient temperature range -10° C to +35° C
during operation:
