HK Audio L.U.C.A.S PERFORMER User Manual

TITEL:
ERSTELLT VON:
BLATT:
AM:
ZEICHNUNGS-NR.:
66606 St. Wendel / Germany
VERSION:
REVISION:
GEPRÜFT/
FREIGEGEBEN VON:
AM:
WERKSTOFF:
OBERFLÄCHE:
DATEINAME:
BLÄTTER
INDEX
ÄNDERUNG
ZEICHNER
HK2005-EX-R07-1C-SAT-COMPLETE
HK2005 - L.U.C.A.S. Performer
EXPLODED DRAWING SAT COMPLETE
HK2005-EX-R07-1C
C. LORIS 2
2
18.03.2008
C1
N/A
Pos. part-no. 1 description Titel quantity
1 340141 Lucas Impact front grille assembly Lucas Impact Frontgitterbaugruppe Bass 1
2 400279 Lucas Performer Top empty cabinet 40 Holzgeh.Lucas Performer Top 1
3 520125 52 crossover assembly Performer Sat 52 Freqw. Lucas Performer Top 1
4 972008 damping wool Dämmwolle Hochbauschvlies 1
5 972047 PE foam tube PE-Schaumstoff-Röhrchen 8
6 974004 hexagon socket head cap screw, M4x25, zinc plated Inbusschraube M4*25 vz 4
7 974020 hexagon socket head cap screw, M5x20, black Inbusschraube M5x20sw 4
8 974080 cross recessed panhead screw, M4x30, zinc plated Linsenschraube M4 x 30 vz 4
9 974096 ABC-Spax S, countersunk head, Pozidrive, 5x25, black Spax Senkkopf, 5*25 sw 4
10 974103 toothed lock washer, D=4.3, AZ, zinc plated Fächer-Scheibe az, 4,3 vz 4
11 974105 hexagon nut, class 8, M5, zinc plated Sechskantmutter M4 vz 4
12 974107 plastic PCB spacer, 4.2x8x10, Polyamid black Dist.Hülse PE 4,2*8*10 [mm] 1
13 974216 hexagon socket countersunk head screw, M5x25, black Inbussenkschraube M5x25 sw 4
14 974419 ABC-Spax-S screws for backwall, 4x30, black Rückwandschraube, 4*30 sw 2
15 976001 rubber foot square, self-adhesive, black Gummifuss quadr. selbstkleb. sw 1
16 976015 plug AD=1705 PA, black Lochstopfen AD=1705 PA-schwarz 4
17 976094 plastic dish 3403 HKBS! DART ! Griffschale 3403 HKBS! DART ! 1
18 976133 tilt unit, 80°, MonoTilt (TM) Ständerflansch ´Mono Tilt´ 80° 1
19* 982037 sealing tape 2x6mm Iso-Zell-Band fadenvers. 2*6mm 1,54 lfdm
20* 986016 foam glue, Alfa D 4572 Klebstoff Alfa D 4572 xxx
21 994069 horn VT 108 1" (Junghans) Horn VT 108 1" (Junghans) 1
22 994173 SICA CD 83.26/380TW-8Ohms SICA CD 83.26/380TW-8Ohms 1
23 994189 SICA LP 209.65/N220 T 8 Ohms SICA LP 209.65/N220 T 8 Ohms 1
1B 211106 UPDATE CROSSOVER C. LORIS
1C 180308 update service-no. and drawing-no. C. LORIS
