7 Technical Specifications
L.U.C.A.S PERFORMER Subwoofer
Inputs/outputs:
Line In: XLR female, 1/4" combination jack
(pin 1= ground; 2= +, 3= -)
Input: Electronically balanced & floating
Input impedance: 47 k ohms
Sensitivity: 0 dBV (=1V)
Max. input level: + 20 dBu
Parallel out: XLR male (pin 1= ground; 2=+, 3= -)
Speaker outputs: Speakon
®
NL 4 (pin 1+= +, 1-= -)
Amplifiers:
Subwoofer output: 1x 500 W RMS / Class D power amp
Satellites output: 2x 200 W RMS / Class D power amp
Protective circuits: MultiBand limiter
Speakers:
Woofer: 1x 15"
Subwoofer frequency response: 47 Hz -130 Hz, ± 3 dB
38 Hz -130 Hz, - 10 dB
SPL 1W / 1m: 101 dB (half space)
Max. SPL / 1m: 126 dB @ 10% THD (half space)
Weights and measures:
Weight: 29,5 kg/ 64,9 lbs
Dimensions (WxHxD): 47.5 cm x 47 cm x 58.5 cm
without casters 18-3/4" x 18-1/2" x 23"
L.U.C.A.S PERFORMER Satellite
Inputs:
Speaker input: Speakon
®
NL 4 (pin 1+= +, 1-= -)
Speakers:
Woofer: 1x 8"
Driver: 1x 1"
Directivity: 60° x 40° CD horn
Overall nominal impedance: 8 ohms
Nominal power handling: 200 W RMS
SPL 1W / 1m: 102 dB (half space)
Max. SPL / 1m: 124 dB @ 10% THD (half space)
Frequency response: 130 Hz - 19 kHz, +/- 3 dB
(via Controller)
Crossover frequency (passive): 2.4 kHz/ 12 dB / octave
Driver protection: Dynamic protective circuit
Pole mount: HK Audio MonoTilt™ 36 mm, -10°
Weights and measures:
Weight: 7,2 kg/ 15,8 lbs.
Dimensions (WxHxD): 26 cm x 38,5 cm x 28,5 cm
10-1/8" x 15-1/8" x 11-1/4"
General electrical data:
Protection class 1 (protectively earthed)
Max. current consumption: 4.4 A (220 – 240 V) • 8 A (110 – 120 V)
Max. power consumption: 1000 Watts
Mains voltage range +/- 10%
Ambient temperature range
during operation: -10° C to +35° C
