GENERAL
INTRODUCTION
This manual is for the Hobart HS Series Slicer.
Procedures in this manual will apply to all models
unless specified.
All information, illustrations and specifications
contained in this manual are based on the latest
product information available at the time of printing.
Home Position
Many procedures state the carriage transport
assembly should be moved to home position. The
carriage transport assembly is in home position when
it is pulled all the way to the operator end of the slicer.
Models
HS6 Manual HS6N* Manual
HS7 Automatic HS7N* Automatic
HS8 Manual HS8N* Manual
HS9 Automatic HS9N* Automatic
*N models have a non-removable knife.
The slicer knife is very sharp.
Exercise extreme caution when working near the
knife.
Features
Listed are the finish, features and option differences
between the models.
SLICER MODELS
Features HS6 HS7 HS8 HS9
Sharpener Housing
Mount Finish
BB BB A A
Slicer Base Finish BB BB A A
Tray Support Assembly
Finish
BB BB A A
Automatic Shut-Off N/A N/A S S
Cleaning Leg S S S' S'
S'= Lift Assist Cleaning Leg
N/A = Not available.
S = Standard on this model.
A = Anodized finish.
BB = Polished and ball burnished finish.
• 10 rib Poly V-Belt driven knife.
• Carriage Home Switch - The knife motor will not
start unless carriage unit is in home position.
(HS7 home for auto only, HS8, HS9)
• Interlock Switch - When carriage is interlocked,
knife motor will only run while the ON button is
pressed. (HS8, HS9)
• Gauge Plate Closed To Stop Switch - Turns off
knife motor when gauge plate is closed from
open position. (HS8, HS9)
• Knife Reset Switch - Turns off knife motor if
carriage tray is inactive for 30 seconds. (HS8,
HS9)
• No voltage release - Requires the slicer to be
manually re-started after a power interruption.
Electrical Components
SLICER MODELS
Electrical
Components
HS6 HS7 HS8 HS9
1MTR Knife Motor X X X X
Carriage Home
Switch
X X X
Interlock Switch X X
Knife Reset Switch X X
Gauge Plate
Closed To Stop
Switch
X X
SPECIFICATIONS
Electrical
100-120/60/1 (5 amps)
200-240/50/60/1 (2.5 amps) also available.
Motor
Knife ½ H.P.
Cord and Plug
A six foot flexible three wire cord and plug is standard
equipment.
120V NEMA 5-15P
230V NEMA 6-15P
Thickness
Adjustable to slice a thickness up to 1-1/4".
Carriage Travel
12-1/2"
HS Series Slicer - GENERAL
F45476 Rev. A (0313) Page 6 of 85
