OM-316 Page 28
Return To Table Of Contents
WORK
220
PRI
SEC
T1
S.O.P.
GRN
VOLT
ONLY
S2
AC HIGH
AC LOW
ELECTRODE
POWER
CORD
FM
S1
SA-191 366
Figure 6-9. Circuit Diagram For 300 (220 Volts) Models
SA-191 367
WORK
CONNECTED FOR 400 VOLTS
PRI
SEC
T1
GRN
S2
ELECTRODE
S1
230V
1234 4
CONNECTED FOR 230 VOLTS
PRI
T1
132
POWER
CORD
FMFM
Figure 6-10. Circuit Diagram For 300 (230/400 Volts) Models

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hobart STICKMATE LX and is the answer not in the manual?

Hobart STICKMATE LX Specifications

General IconGeneral
Input Voltage230 V
Input PhaseSingle Phase
Input Frequency50/60 Hz
Welding ProcessStick (SMAW)
TypeStick Welder
Electrode Size Range1/16 in to 5/32 in
