06-5
6.5 Tables
Elevating table
To lower
• Turn the locking bolt
j
180°.
• Press on table top to lower the table.
• Turn the locking bolt
j
back and secure the
table top.
To turn
• Loosen the knurled screw
k
.
• Turn the table in the desired (excentric) direction.
• To lock the table, tighten the knurled screw
k
.
1 2
6.4 TV mount
As an option, all of the models that are not tted
with an extendable media shelf or media oval
can be tted with a TV mount.
To unlock
•
Pull the pin
j
up.
• Swivel the support arms
k
to the desired
position.
To lock
•
Fold up the TV mount until you can hear the
pin
j
click into place.
Before you start your journey, retract
the TV mount and lock it into place.
1
2
