Hobie Mirage Tandem Island User Manual

Maintenance and Care | 41
hobiecat.com
Rudder Tuning
Loosen screw clamping
the rudder line
1
2
Pull the slack out of the
rudder line making sure
the steering handle is
still straight. If they are
not straight, adjust the
lines accordingly.
Wrap the line around the
screw and tighten it to
clamp the line and hold it
in place.
3
Steering Riser
Remove the screw holding on
the steering handle and remove
the handle.
1
2
Place the steering riser over the
steering crank with the handle
on top. Place a few drops of the
provided Loctite® on the end of
the screw and install to the boat
with the provided longer screw.
Make sure the screw is screwed
in tight.
Your Island comes with the option to raise the steering handle up higher if it is
more comfortable for you. Follow the steps below to add the steering riser.

Hobie Mirage Tandem Island Specifications

General

Length	18' 6" / 5.64 m
Capacity	600 lbs / 272 kg
Hull Construction	Rotomolded Polyethylene
Seating Capacity	2
Sail Area	90 sq ft / 8.4 sq m
Weight	240 lbs / 109 kg
