1. Status Display in Transmitter Mode
●
a receiver,
X
is displayed at the signal
strength display area on the left of the
top information bar.
●
receiver, the connected receiver number
and the signal strength are displayed at
the signal strength display area on the
left of the top information bar.
●
video source, the video resolution is
displayed in the middle of the top
video source connected,
NO VIDEO
is
displayed instead.
2. Status Display in Receiver Mode
●
transmitter,
X
is displayed at the signal
strength display area on the left of the
top information bar and
NO VIDEO
is
displayed in the middle of the top infor-
mation bar.
●
transmitter, the device number and the
signal strength are displayed at the
signal strength display area on the left
of the top information bar.
●
connected to a video source, the video
resolution is displayed in the middle of
the top information bar.
