Page 9
wING
NUT
FRONT HANDLE
BOLT
wASHER
Fig. 3
NOTE: If the button does not release completely in the
positioning hole, the shafts are not locked into place.
Slightly rotate from side to side until the button is locked
into place.
Tighten the knob securely.
WARNING:
Be certain the knob is fully tightened before operating
equipment; check it periodically for tightness during use
to avoid serious personal injury.
REMOVING THE ATTACHMENT FROM THE
POWER HEAD
For removing or changing the attachment:
Loosen the knob.
Push in the button and twist the shafts to remove and
separate ends.
ATTACHING THE FRONT HANDLE
See Figure 3.
Loosen and remove the wing nut, washer, and bolt from
the handle.
Install the handle on the drive shaft housing at the loca-
tion indicated by the label on the shaft.
Reinstall the bolt, washer, and wing nut. Tighten wing nut
to secure.
