Homelite UT60526 Repair Sheet

3
HOMELITE
GAS CULTIVATOR – MODEL NO. UT60526
30 660934002 Screw (M5 x 60 mm T.F.) ....................................... 1
31 638566001 Clutch Drum .......................................................... 1
32 678187002 Clip ........................................................................ 1
33 519811001 Plate Adapter ........................................................ 1
34 660466003 Screw (M5 x 40 mm T.F.) ....................................... 3
35 308236002 Wheel Assembly (6 in. Dia.) ................................... 2
36 638635001 Cotter Pin .............................................................. 2
37 638017002 Washer .................................................................. 2
38 310260001 Frame Assembly ................................................... 1
39 661606001 Screw (M5 x 19 mm Pan Hd.) ............................... 3
40 760679001 Switch ................................................................... 1
41 660973014 Bolt (M8 x 25 mm Hex Hd) .................................... 1
42 678355002 Hex Nut (M8) ......................................................... 2
43 950119010 Foot Warning Label ............................................... 1
44 941484003 Starting Label ........................................................ 1
45 940654088 Combustion Warning Label ................................... 1
46 941484004 Model Label .......................................................... 1
47 940654082 Warning Label ....................................................... 1
48 941484001 Icon Warning ......................................................... 1
49 941485007 Hang Tag ............................................................... 1
NOT SHOWN:
50 310266001 Airbox Cover ........................................................ 1
51 901688001 Filter ...................................................................... 1
52 570367001 Airbox Seal ............................................................ 1
53 310816001 Fuel Cap ................................................................ 1
54 870174001 * Spark Plug (Champion RCJ-6Y)............................ 1
987000551 Operator’s Manual .................................................1
987000571 Replacement Parts List ......................................... 1
5-25-10
(REV:04)
1 220029010 Gear Box Assembly ..............................................1
2 620888001 Drive Shaft .............................................................1
3 308693001 Tine A, Outer Right ................................................1
4 308693002 Tine B, Inner Right................................................. 1
5 308693003 Tine C, Inner Left ...................................................1
6 308693004 Tine D, Outer Left .................................................. 1
7 638717001 Lower Handle ........................................................ 1
8 308629002 Upper Handle Assembly .......................................1
9 310263001 Front Handle.......................................................... 1
10 661527001 Carriage Bolt (M8 x 60 mm) ..................................2
11 660669001 Screw (8-16 x 1/2 in.) ............................................1
12 638660001 Ball Bearing (6003zz) ............................................. 1
13 660643001 Bolt (1/4-20 x 1.5 in.) ............................................. 4
14 690696001 Washer (Curved) .................................................... 4
15 678013001 Washer .................................................................. 4
16 310261001 Tine Shield Assembly ............................................ 1
17 308213005 Wheel/Drag Stake Assembly
(Incl. Key No. 35-38) .............................................. 1
18 900755001 Felt Washer ........................................................... 2
19 638001004 Clevis Pin .............................................................. 2
20 678135001 E-Clip .................................................................... 1
21 518256002 Trigger ................................................................... 1
22 519790003 Knob (M8) .............................................................. 3
23 308330004 Throttle Cable Assembly (Incl. Key No. 40) ...........1
24 519807001 Cable Clip ..............................................................1
25 678132001 Lock Nut (1/4-20) ..................................................8
26 638132001 Pin ......................................................................... 1
27 660643002 Bolt (1/4-20 x 1 in.) ................................................4
28 519794001 Engine Adapter...................................................... 1
29 660970010 Screw (M4 x 95 mm) ............................................. 1
PARTS LIST (FIGURE A)
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
* STANDARD HARDWARE ITEM — MAY BE PURCHASED LOCALLY

Homelite UT60526 Specifications

General

Brand	Homelite
Model	UT60526
Category	Tiller
Language	English
