5
HOMELITE
GAS CULTIVATOR – MODEL NO. UT60526
1 300960002 Clutch Assembly ................................................... 1
2 638090001 Washer .................................................................. 1
3 638284002 Spacer Tube .......................................................... 1
4 660970003 Screw (M4 x 20 mm) ............................................. 1
5 690969001 Washer .................................................................. 1
6 660970001 Screw (M4 x 16 mm) ............................................. 2
7 308889006 Lower Housing w/Starter Assembly
(Inc. Key Nos. 8-14) ............................................... 1
8 308981009 Lower Housing Assembly ..................................... 1
9 900849010 Starter Rope .......................................................... 1
10 638033001 Spring & Container Assembly ............................... 1
11 511731001 Grip ....................................................................... 1
12 518501001 Starter Pulley ......................................................... 1
13 638389001 Pulley Retainer ...................................................... 3
14 660967001 Screw (M4 x 14 mm) ............................................. 3
15 650017001 Washer .................................................................. 1
16 308811001 Flywheel Assembly ................................................ 1
17 309960013 Short Block Assembly ........................................... 1
18 901550001 Crankcase Cover Gasket ...................................... 1
19 638337003 Crankcase Cover................................................... 1
20 660925003 Screw (M4 x 12 mm) ............................................. 6
21 518726004 Top Housing .......................................................... 1
22 660466001 Screw (M4 x 18 mm) ............................................. 4
23 901551001 Intake Gasket ........................................................ 1
24 518497001 Heat Dam .............................................................. 1
25 901552001 Carburetor Gasket ................................................. 1
26 518690001 Baffle Plate ............................................................ 1
27 308054032 Carburetor ............................................................. 1
28 519792001 Air Box Base ......................................................... 1
29 570367001 Air Box Seal ........................................................... 1
30 660454007 Muffler Bolt ............................................................ 2
31 901452004 Muffler Gasket ....................................................... 1
32 308990018 Muffler Assembly................................................... 1
33 638442002 Heat Shield ............................................................ 1
34 660638003 Screw (10-24 x 2-1/8 in.) ....................................... 2
35 309264003 Ignition Module ..................................................... 1
36 660968001 Screw (M4 x 19 mm) ............................................. 2
37 308863028 Lead Wire Assembly ............................................. 1
38 310264002 Fuel Tank with Cap Assembly ............................... 1
39 638576004 Flat Washer ........................................................... 1
40 660493001 Screw (M5 x 17 mm) ............................................. 1
41 660970008 Screw (M4 x 19 mm, Shoulder) UT60526 Only) .... 2
660970002 Screw (M4 x 16 mm, Shoulder) ............................. 2
42 638588001 Bracket (UT60526 Only) ........................................ 2
43 570256001 Bumper (UT60526 Only) ........................................ 2
44 561635001 Primer Bulb ........................................................... 1
45 518824001 Choke Lever .......................................................... 1
PARTS LIST (FIGURE B)
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
