Place the Fan Blade onto the motor spindle.
Note: The groove in the rear centre of the fan blade aligns with a T-bar on the motor
spindle to ensure correct positioning.
Fix the blade into place by gently hand tightening the spinner nut anticlockwise onto
the end of the motor spindle. The spinner is self-tightening when the motor starts so do
not force it, just nip it up.
Open up all locking clips on the sides of the rear safety grille
Place the safety grille into position and secure it by closing the clips over the outer rim.
The screw and nut at the top of the grille must be fitted.
