Honda 2007 Element - Page 241

− −
No. Amps. Circuits Protected
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
30 A
15 A
7.5 A
20 A
15 A
15 A
15 A
15 A
10 A
30 A
20 A
40 A
40 A
40 A
15 A
15 A
15 A
30 A
100 A
50 A
Condenser Fan
Small Light
Interior Light
Cooling Fan Motor
Hazard
IGP
Horn, Stop
DBW
Back Up
VSA Motor
Rear Defroster
Heater Motor
Power Window Main
Option
Left Headlight
Door Lock
Right Headlight
VSA MTR FSR
Battery
IG1 Main
Spare Fuses
21 25 7.5A 30A
Fuse Locations
238
UNDER-HOOD FUSE BOX
