Adjusting the Clutch Lever
Freeplay
#
Upper Adjustment
Attempt adjustment with the upper clutch
cable adjuster first.
1.
Loosen the upper lock nut.
2.
Turn the upper clutch cable adjuster until
the freeplay is 10 - 20 mm (0.4 - 0.8 in).
3.
Tighten the upper lock nut and check the
freeplay again.
Clutch u Adjusting the Clutch Lever Freeplay
Maintenance
95
Continued
Upper clutch
cable adjuster
Upper lock nut
+
-
To Next Page
