SPECIFICATIONS
1-7
EG5500CX/EG6500CX
DIMENSIONS AND WEIGHTS
ENGINE
Model EG5500CX EG6500CX
Type UH RHH, KH, MH, RH, LDH, LTH, SH, SKH
Description code EBCC
Overall length 681 mm (26.8 in)
Overall width 530 mm (20.9 in)
Overall height 571 mm (22.5 in)
Dry weight 84.0 kg (185.2 lbs)
Operating weight 102.5 kg (226.0 lbs)
Model GX390H1
Description code GCAFH
Type 4 stroke, overhead valve, single cylinder, inclined by 25°
Displacement
389 cm
3
(23.7 cu–in)
Bore x stroke 88.0 x 64.0 mm (3.46 x 2.52 in)
Compression ratio 8.0 ± 0.2
Ignition system Transistor magneto ignition
Ignition timing B.T.D.C. 25° ± 2 at no load
Spark plug BPR5ES (NGK)
Lubrication system Forced spray
Oil capacity
1.1 (1.2 US qt, 1.0 Imp qt)
Recommended oil SAE 10W – 30 API service classification SE or later
Cooling system Forced air
Starting system Recoil starter
Stopping system Ignition primary circuit ground
Carburetor Horizontal type, butterfly valve
Air cleaner Semi-dry type
Governor Mechanical centrifugal
Breather system Flat valve type
Fuel used Regular unleaded gasoline with a pump octane rating 86 or higher
