IGNITION SYSTEM
8-8
SWITCH INSPECTION
Remove the oil level switch (page 14-4).
Check for continuity between the oil level switch (1) wire
connector (Yellow) terminal and switch body with
an ohmmeter.
Check the float by dipping the switch into a container of
oil. The ohmmeter reading should go from continuity to
no continuity as the switch is lowered into the oil.
(1)
LOW OIL LEVEL
(CONTINUITY)
NORMAL OIL LEVEL
(NO CONTINUITY)
