Honda EG5000CX - Page 57

SERVICE INFORMATION
2-26
JUNCTION BOX/CONTROL PANEL SIDE (CXS-RHH TYPE)
JUNCTION BOX 10P
CONNECTOR
JUNCTION BOX 1P
CONNECTOR
MAIN WIRE
HARNESS SIDE
Terminal
number
Wire color
1Br
2–
3Y/G
4Y/G
5Br
6–
7Bl/W
8–
9W
10 Bu
MAIN WIRE
HARNESS SIDE
MAIN WIRE
HARNESS SIDE
Terminal
number
Wire color
1Y/G
COMBINATION SWITCH
8P CONNECTOR
CIRCUIT BREAKER
4P CONNECTOR
JUNCTION BOX 8P
CONNECTOR
VOLT METER 3P
CONNECTOR
Terminal
number
Wire color
1–
2–
3–
4–
5–
6–
7–
8W
Terminal
number
Wire color
1R
2–
3–
4–
MAIN WIRE
HARNESS SIDE
VOLT METER
SIDE
Terminal
number
Wire color
1W
2–
3R
Terminal
number
Wire color
1Bu
2–
3G
4Bl
5–
6W
7G/W
8Bl/W
COMBINATION
SWITCH SIDE
WARNING INDICATOR
2P CONNECTOR
WARNING
INDICATOR SIDE
Terminal
number
Wire color
1R
2W
Bl Black Br Brown
Y Yellow O Orange
Bu Blue Lb Light blue
G Green Lg Light green
R Red P Pink
W White Gr Gray
