Honda EG5000CX - Page 72

SERVICE INFORMATION
2-41
CONTROL PANEL SIDE (CX-UH TYPE)
(+) DC OUTPUT
TERMINAL
(–) DC OUTPUT
TERMINAL
CIRCUIT PROTECTOR
CONNECTOR
CIRCUIT PROTECTOR
CONNECTOR
GROUND
TERMINAL
MAIN WIRE
HARNESS SIDE
Terminal
number
Wire color
1Bl/W
2Br
3Bu
4Y/G
CIRCUIT BREAKER
TERMINAL
Terminal
number
Wire color
Y/G
Terminal
number
Wire color
W/R
W/R
Bl Black Br Brown
Y Yellow O Orange
Bu Blue Lb Light blue
G Green Lg Light green
R Red P Pink
W White Gr Gray
Terminal
number
Wire color
W/R
Bl/R
R
R
R
Y/G
W
R
Y/G
W
CIRCUIT BREAKER
TERMINAL
(WHITE TAPE)
RECEPTACLE
TERMINAL ([B] MARK)
RECEPTACLE
TERMINAL
RECEPTACLE
TERMINAL
RECEPTACLE
TERMINAL
DIODE 4P
CONNECTOR
RECEPTACLE
TERMINAL ([B] MARK)
RECEPTACLE
TERMINAL ([B] MARK)
