MAINTENANCE
3-8
COMBUSTION CHAMBER CLEANING
Remove the cylinder head (page 13-3).
Clean any carbon deposits from the combustion
chamber (1).
FUEL TANK AND FILTER CLEANING
Drain the fuel into a suitable container.
Remove the fuel tank (1) and fuel tank strainer (2)
(page 5-4).
Clean the fuel tank strainer and fuel tank with non-
flammable solvent, and allow them to dry thoroughly.
Install the fuel tank (page 5-4).
Check the installation part of the fuel tank for any sign
of fuel leakage.
(1)
Gasoline is highly flammable and explosive. You
can be burned or seriously injured when handling
fuel.
• Keep heat, sparks, and flame away.
• Handle fuel only outdoors.
• Wipe up spills immediately.
(2)
(1)
