Four Wheel Kit Installation
TORQUE:
GENERATOR
SIDE
LONGER
4 28 mm SPLIT PIN (4)
WHEEL (4)
8mm
FLANGE NUT (8)
LOCK PLATE
20 mm PLAIN WASHER (5)
REAR WHEEL SHAFT
FRONT WHEEL SHAFT
8 16 mm FLANGE BOLT (8)
Install the lock plate and four wheels on the wheel shaft using the
plain washers and split pins.
Install the front wheel shaft on the front side nearest the engine.
Install the wheel shaft assembly on the generator using eight 8 16
mm flange bolts.
24 29 N·m (2.4 3.0 kgf·m , 17 22 lbf·ft)
1.
2.
