Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
Insert the socket back into the
headlight assembly. Turn it
clockwise to lock it in place.
Testthelightstomakesurethe
new bulb is working.
Place a cloth between the trim of
the lens and the body, at the top of
the lens. Remove the front side
marker light assembly by carefully
prying on the trim of the lens with
a small flat-tipped screwdriver.
Pull the bulb straight out of its
socket. Push the new bulb straight
into the socket until it bottoms.
Install the front end of the air
intake duct.
(Driver’s side)
Remove the socket from the light
assembly by turning it one-quarter
turn counterclockwise.
1.
3.
4.
5.
2.
3.
6.
Lights
Maintenance
Replacing a Front Side Marker
Light Bulb
260
