HONDA EX4D/5D (E) 36ZC8625 -21-
Operation:
1. Start the engine and make sure the pilot lamp comes on.
2. Choose the proper voltage by changing the voltage selector switch (B, L,
C types only).
NOTE: The type B generator should not be used with appliances rated at
115V and 230V. The type C and L generators are for 120V and 240V
appliances.
Although voltage adjustment is usually not required, fine adjustments may
be made by turning the voltage adjustment knob. Use the generator at the
specified voltage (Except B, C, L types).
VOLTAGE SELECTOR
(B type)
VOLTMETER
VOLTAGE ADJUSTMENT KNOB
