48
No electricity at the AC receptacles:
Replace the electrical ap-
pliance or equipment.
Take the electrical ap-
pliance or equipment to an
electrical shop for repair.
Is the AC circuit breaker
ON?
When the GFCI RESET button is not extended
Unplug all appliances
and equipment, and in-
spect the GFCI operation.
(refer to page 18)
When the GFCI RESET button is extended
Replace the electrical ap-
pliance or equipment.
Take the electrical ap-
pliance or equipment to an
electrical shop for repair.
Is the AC circuit protector
ON?
Check the electrical ap-
pliance or equipment for
any defects.
Take the generator to an au-
thorized Honda generator
dealer.
Turn the AC circuit breaker
ON. (page 14)
Reset the circuit protector.
(page 15)
Take the generator to an au-
thorized Honda generator
dealer.
NO
YES
DEFECTS
NO DEFECTS
The GFCI RESET button
is extended again.
YES
NO
The GFCI RESET button
is not extended.
07/11/08 17:41:33 31Z22600_049
To Next Page
