Electrical Trouble u Blown Fuse
123
❙
Fuse Holder Fuses
1.
Remove the seat.
2
P. 78
2.
Remove the starter magnetic switch
cover.
3.
Pull the main fuse B and other fuse out
one by one with the fuse puller and check
for a blown fuse. Always replace a blown
fuse with a spare of the same rating.
uSpare fuses are provided in the fuse
box.
uA fuse puller is provided in the fuse box
cover.
4.
Reinstall parts in the reverse order of
removal.
Starter magnetic switch cover
Main fuse B
FI fuse
Fuse holder
If a fuse fails repeatedly, you likely have an electrical
problem. Have your motorcycle inspected by your dealer.
