18
Power Supply Installation
• Find a suitable location for the power supply and mount using the self-tapping
screws.
• Use the wiring diagram on the next page to connect to power.
• When all the other components are properly installed connect the UV lamp cable
to the power supply cable.
M34663
ALIGN FLANGES
2.
1.
• Make sure the flanges are aligned
and then push the connectors
firmly together. A tight connection
ensures a proper water-resistant
seal. See image at right.
• Turn on the power and use the lamp
handle or sight glass to confirm
that the UV Lamp is operating.
To Next Page
