Honeywell CN100 - Page 31

31
Description Model or
Part
Number
FTE Link B Cables
FTEB Ethernet Cable, STP CAT5,
Green, 24 inches (610 mm) long
51305980-
224
FTEB Ethernet Cable, STP CAT5,
Green, 36 inches (1 m) long
51305980-
236
FTEB Ethernet Cable, STP CAT5,
Green, 48 inches (1.2 m) long
51305980-
248
FTEB Ethernet Cable, STP CAT5,
Green, 60 inches (1.5 m) long
51305980-
260
FTEB Ethernet Cable, STP CAT5,
Green, 84 inches (2 m) long
51305980-
284
Ethernet Ports
Connect Ethernet ports A and B to their respective FTE switches.
ATTENTION: Confirm the location to be non-hazardous prior to
adjusting the switch.
ATTENTION: Veuillez-vous assurer que vous êtes dans une zone
d’atmosphère non explosive avant d’ajuster le sélecteur.
The CN100 controller has 2 Ethernet ports on the NAM and use RJ45
type connectors. See the following figure for the pin assignment:
Figure 4-6: Pin Assignment of RJ45
