34 GWF-7075 Addressable Fire Alarm Control Panel Manual — P/N LS10147-002GF-E:E 06/11/2019
Section 5: Velociti
®
and SWIFT
SLC Device Installation
5.1 List of Velociti SLC Devices
The following Velociti mode SLC devices can be used with the control panel. See the device installation instructions for more informa-
tion (packaged with the device). For additional information on the compatible devices, refer to the Compatibility Addendum for
Gamewell-FCI Manuals, P/N:9000-0427-L8.
5.2 SWIFT™ Wireless SLC Devices
The VW-GATE acts as a bridge between a group of wireless fire devices and a SLC loop on the GWF-7075. It is powered by the SLC
loop or by a regulated, external 24VDC UL-listed power supply. Available wireless devices include a photo detector, a photo/heat detec-
tor, a fixed-temperature heat detector, a rate-of-rise detector, and a monitor module. For updated details about wireless devices, system
setup and operation see the SWIFT
®
Smart Wireless Integrated Fire Technology Manual # P/N LS10036-000GF-E.
5.3 Maximum Number of Devices
The GWF-7075 supports Velociti and SWIFT devices on one GWF-7075 system. The maximum number of devices per system varies
depending on device protocol Device support is as follows:
Velociti mode–An GWF-7075 system can support a total of 75 Velociti detectors and 75 Velociti modules. For a maximum of 150
points.
SWIFT Wireless Devices–A SWIFT Gateway system supports up to 50 devices: 1 SWIFT Gateway and up to 49 (in any
combination) wireless detectors and monitor modules. Multiple Gateways can be used. See the SWIFT manual
P/N LS10036-000GF-E for more information.
!
CAUTION: To avoid the risk of electrical shock and damage to the unit, turn off the power at the control panel, when you install or service
the panel.
P ar t N um be r M od el N am e/ Description Install Sheet PN Part Number Model Name/Description Install Sheet PN
ASD-PL2F Photoelectric smoke detector I56-3560-00 AMM-4SF Addressable zone interface module I56-3552-00
ASD-PTL2F Photoelectric smoke detector
with thermal (135°F
MMI-6SF Six zone interface module I56-2742-00
ASD-PL2FR Photoelectric replacement
smoke detector with remote test
capability in DNR
I56-3568-00 AOM-2SF Supervised control module I56-3550-00
MCS-Acclimate2F Multi criteria photoelectric
smoke detector with thermal
(135°F)
I56-3560-00 MMO-6SF Six circuit supervised control module I56-2740-00
ABD-2F Reflected beam smoke detector
without test feature
I56-2741-00 ASD-PL3 / IV Photoelectric smoke detector. white or
ivory
I56-6535-00
ABD-RT2F Reflected beam smoke detector
with test feature
I56-2741-111 ASD-PL3R / IV Photoelectric smoke with remote test
capability. white or ivory
I56-6536-00
DNR/DNRW Duct smoke detector housing.
Non-relay (ASD-PL2FR or
ASD-PL2Fsold separate)
I56-3051-00 ASD-PTL3 / IV Photoelectric smoke detector with
thermal (135°F). white or ivory
I56-6535-00
ATD-L2F Fixed temperature thermal
detector (135°F)
I56-3557-00 ATD-L3 / IV Programmable thermal detector. white
or ivory
I56-6537-00
ATD-RL2F Rate-of-rise thermal detector
with 135° fixed temperature
ATD-L3R / IV Rate-of-rise thermal detector with 135°
F fixed temperature. white or ivory
I56-6537-00
ATD-HL2F Fixed high temperature thermal
detector (190°F)
ATD-L3H / IV Fixed high temperature thermal
detector (190°F). white or ivory
I56-6537-00
MS-7ASF Addressable single action pull
station
I56-3564-00 MCS-COF CO Smoke Detector I56-3872-00
MS-7AF Addressable dual action pull
station
I56-3555-00 B210LP 6" mounting base I56-0595-00
M500X Fault isolator module I56-1382-00 B224BI / IV 6" isolator base. white or ivory I56-0725-00
AMM-4F Monitor module I56-4071-00 B224RB / IV 6" relay base. white or ivory I56-3737-00
AMM-2F Mini monitor module I56-3554-00 B200SR / IV 6" temporal sounder base. white or
ivory
I56-3392-00
AMM-2IF Dual input monitor module I56-2750-00 B200S / IV Intelligent Sounder Base. white or
ivory
I56-3387-00
MMI-10F 10 input monitor module I56-2743-00 B501 4" mounting base I56-0357-00
AOM-2RF Addressable relay module I56-3551-00 B200SR-LF / IV Low Frequency Sounder Base. white
or ivory
I56-4152-00
MMO-6RF Six relay control module I56-2739-00 B200S-LF / IV Low Frequency Sounder Base. white
or ivory
I56-4151-00
AMM-2RIF Dual relay/monitor module I56-3728-00 MCS-PTIR Photo/Thermal/IR Multi-Criteria I56-6620-00
MCS-COF3 Photo/CO Thermal/IR, Multi-
Criteria, CO
I56-6604-00
Table 5.1 Velociti Mode Devices
