2. SETUP (ADVANCED OPTIONS) T775A/B/M SERIES 2000 CONTROLLER
25 62-0254–03
Fig. 56. Setup - Outputs - Options - Min Off Time.
2.3.3.2. MIN OFF (minimum off time for all relays)
This is the minimum number of seconds of “off time” for
all relays.
1. Press the X button to display the Min Off value.
2. Use the S and T buttons to increase/decrease the
desired number of seconds from 0 to 990 seconds
in 10 second increments.
Default: 0 (zero)
Range: 0 to 990 seconds
3. Press the X button to accept the seconds and
display the DI OPTIONS.
NOTES:
1. The minimum off time applies to all relay
outputs.
2. When minimum off time is active, relays
waiting to be energized display a flashing
square underneath the relay number on the
home screen.
3. If the minimum off time is not equal to zero
(0), the minimum off time activates at power-
up. To manually override, press the W button
at any time.
Fig. 57. Setup - Outputs - Options - DI Options.
2.3.3.3. DI OPTIONS (digital input options)
The DI Option you select applies to all outputs. This
option overrides any Setpoint/Setback values entered in
the Schedule.
1. Press the X button to display the DI Option selec-
tions.
2. Use the S and T buttons to highlight DISABLE,
SETBACK, or IGNORE.
Default: DISABLE
3. Press the X button to accept the value and display
the SHOW RT option.
When the digital input (DI) closes, all outputs follow the DI
option value (Disable, Setback, or Ignore):
• DISABLE disables the outputs; relays return to de-
energized state and Mod outputs return to 0% output.
• SETBACK enables a setback temperature value to be
programmed for each output.
— To program the Setback temperature, see Fig. 32
on page 16.
• IGNORE causes the digital input to have no effect on
the Relay or Mod outputs.
Fig. 58. Setup - Outputs - Options - Show Runtime.
2.3.3.4. SHOW RT (show run time hours)
1. Press the X button to display the Show RT values.
2. Use the S and T buttons to select YES or NO.
Default: YES
3. Press the X button to accept the value and return to
the Options menu.
Selecting YES shows the RT (run time) hours for each
relay on the home screen displays.
NOTE: Run times can be reset to zero for each individ-
ual relay. You must do this for each relay that
you want to reset to zero. See “2.3.4.3. RESET
RT (run time hours)” on page 28.
