User Interface
The Enabler can be configured and controlled manually through the user interface on the Thor VM1. This section details the
functionality that can be controlled by the user or system administrator.
Parameters and Screen Displays
Screen displays shown in this section are designed to present the end-user with information graphically.
Placement of information on the screen displays may be split between one or many tabbed panels.
Standard Avalanche Enabler parameters that are not supported by Honeywell may be missing or dimmed (visible but unable to
be edited) on the tabbed panels or screen displays.
Enabler Configuration
Depending on the version of the Enabler running on the Thor VM1, the desktop Enabler icon may look like one of the following:
The available configuration options and tabs may vary by Enabler version. The examples shown in this section assume the
latest version of the Enabler is installed on the Thor VM1.
The Enabler user interface application is launched by clicking either the Enabler icon on the desktop or Taskbar or by
selecting Avalanche Enabler from the Programs menu.
The opening screen presents the Thor VM1 user with the connection status and a navigation menu.
Note: Some parameters and features described in this section may not be available if you are not running
the latest version of the Enabler. Contact your representative for upgrades.
5-7
