2 INSTALLATION
10
VERSAFLOW MAG 1000
www.honeywellprocess.com 34-VF-25-54 iss.3 GLO July 14 US
2.7 General requirements
2.7.1 Vibration
2.7.2 Magnetic field
INFORMATION!
The following precautions must be taken to ensure reliable installation.
•
Make sure that there is adequate space to the sides.
•
Protect the signal converter from direct sunlight and install a sun shade if necessary.
•
Signal converters installed in control cabinets require adequate cooling, e.g. by fan or heat
exchanger.
•
Do not expose the signal converter to intense vibration. The flowmeters are tested for a
vibration level in accordance with IEC 68-2-64.
Figure 2-5: Avoid vibrations
Figure 2-6: Avoid magnetic fields
