19
ED 650 E/S - CA 90/120
3. Check that the cannister of detergent (Optional) and
rinsing agent contain sufficient product for daily needs.
4. Turn the mains selector (1). The washing tub will
immediately begin to fill. Once the correct level has
been reached, the water will automatically begin to
heat. This is indicated by a flashing light (5). Wait until
the preset temperature has been reached and the light
(5) becomes fixed.
5. Open the door and pour the quantity of detergent
indicated by the manufacturer directly into the tub. This
operation need not be carried out when the machine is
equipped with the optional dispenser.
6. Choose the cycle length by means of the selector (2).
3.3.b Washing operations (Fig 8)
1. Load the dirty crockery into the basket (as indicated in
Fig. 10).
2. Load the basket with dirty crockery depending on the
configuration.
2. Raise the lid and place the basket with the dirty
crockery in the tub.
3. Close the lid. The washing and rinsing cycle will
automatically begin and the warning light (9) will come
on.
4. The light (9) will go out to indicate that the cycle has
terminated. Now open the door and remove the basket.
5. Add a half of coffee cup of detergent after every 5/6
washes. This operation need not be carried out if the
machine is equipped with the optional dispenser.
The doses are indicative and not binding since they
vary according to the hardness of the water and utilized
type of detergent.
IMPORTANT
Keep the lid shut between cycles to prevent the water in
the tub from cooling.
ATTENTION
Door opening during the cycle will block machine operation
in the same way as an EMERGENCY device.
To interrupt the cycle, open the tub door in the following
way:
• Slightly lift the lid and wait a few seconds for the
pressure of the water in the spray arms to drop and to
then completely rise.
• This operation is very important since it prevents the
operator from being wetted or scalded as during the
rinsing phase, the water reaches a temperature of
90°C.
• The light (9) Fig. 8 will flash. Shut the lid within 10
seconds and the cycle will continue from where it left
off, otherwise light (9) will go out and the cycle must be
re-started from the beginning.
3.3.c Changing the water (Fig. 9)
This operation must be carried out after every 10 cycles or
so, according to the amount of accumulated dirt.
1. Remove the tub filters (25).
2. Switch off the machine as indicated in paragraph 3.3.d,
then lift the overflow (26) and allow the tub to completely
drain.
3. Refit the overflow (26) and the filters (25) in its housing
and repeat the machine preparation operations as
indicated in paragraph 3.3.a.
3.3.d Manual drain (Fig. 1)
(on machines with drain pump only)
To manually empty tha water fraom the tub, turn left the
switch selector (1), the empty is temporized; at the end the
pump will be stopped.
3.3.e Switch-off (Fig. 6)
At the end of the work day, set the line switch (1) to position
“0” OFF, discomnnect the main switch installed prior to the
machine and turn off the water delivery cock.
ATTENTION
Disconnect the main circuit-breaker prior to the machine
and turn off the water delivery cocks if the dishwasher is
faulty or operates badly.
Only allow the manufacturer’s authorized after-sales
service center to make repairs.
3.3.f Alarms (Fig. 8)
The machine will set to the alarm status in the following
cases:
• Tub refilling timeout.
If tank filling fails to terminate within 20 minutes, the
machine will set to the alarm status. This is indicated by
fast flashing warning light (9). Switch off the machine
by turning selector (1) to 0 “OFF” to reset the alarm.
• Overheating.
If the temperature of the water in the boiler exceeds
98°C, the machine will set to the alarm status, inhibiting
all functions and any cycle in progress. The alarm
status is indicated by fast flashing warning light (5).
The alarm automatically disactivates when the tempe-
rature drops below 90°C. Failing this, switch off the
machine by turning selector (1) to 0 “OFF” to reset.
• Heating timeout.
The machine will set to the alarm status if, after 20
minutes continuous boiler heating, the temperature
remains less than 45°C. This is indicated by fast
flashing warning light (5).
Switch off the machine by turning selector (1) to 0
“OFF” to reset.
ATTENTION
Contact the after-sales service center if the alarm
continuously activates.
3.4 LOW LEVEL DETERGENT AND
RINSING AGENT INDICATORS
Before beginning the cycle, make sure that warning lights
(7) and (8) Fig. 8 are off. If one of these lights flashes, this
ENGLISH
