27
ENGLISH
Part 3: For the technician
IMPORTANT
Every operation of installation, electrical or hydraulic
connection, programming, maintanance etc...has to
be carried out by QUALIFIED personnel, authorised
by the manufacturer;
any interventions carried out by UNQUALIFIED per-
sonnell, may compromise the technician’s own safety,
as well as the safety of other personnel (operators,
etc.) or of any other equipment connected to the
washing machine.
The manufacturer declines all responsibility for
accidents or damage to persons or property caused
by failure to comply with the above listed provisions.
If the electrical cord is damaged, it must be repla-
ced by the manufacturer or by its technical service
or by a person with similar qualications.
3.1 INSTALLATION (Fig. 6-7)
- After having removed the packing, make sure that the
machine is in a perfect condition and that all the parts
have been included.
- Position the machine in the required setting.
3.1.a Connecting the drain pipe (Fig. 6)
- Fix the drain pipe (11) to the relative preset outlet.
IMPORTANT
To preview a pavement download with sifoide and to
join to the machine with the exible tube to I equip
making so that the same one or in slope towards the
download.
To make sure moreover that along the same one not
there are throttlings.
To assess that the outlet pipe to wall resists to a
temperature of 70°C.
3.1.b Connection on the water main (Fig. 6-7)
- Screw the end of the ll pipe (12) to a 3/4”G threaded
cock, tting the lter (13 Fig. 7) in between.
ATTENTION
It is essential to connect the cold water delivery pipe to a
throttle cock in order to separate the water main from the
machine itself. Also make sure that there are no sharp
bends.
ATTENTION
It is compulsory to replace the gaskets of the inlet
tube for water supplying, every time it is demounted
and mounted.
ATTENTION
If there is sand in the water main, it will be necessary to
install a lter between it and the machine.
The exercise pressure will not have to be inferior to the 2
advanced bars and to the 4 bars (200-400 kPa).
If the pressure is inferior, increase is advised to the instal-
lation of a pump pressure; if the pressure is advanced,
the application of a pressure reducer.
For having a good result he is advisable to have the water
of entrance with a not advanced hardness to the 10°F.
For advanced hardnesses to use cars with built-in water
softner or water softners to ion exchange or inverse
osmosis.
To respect eventual enforced National or Regional
norms rigorously.
The manufacturer declines all responsibility for da-
mage to the machines caused by failure to comply
with the above listed provisions.
3.1.c Connection to the water main (Fig. 6-7)
DANGER
- Before connecting to the electricity main, always
check that the data pertaining to the power source
correspond to those indicated on the identica-
tion plate (pos. 9 Fig. 5) and that the main electric
power switch installed prior to the machine is
disconnected “0” OFF.
- An appropriately sized omnipolar circuit-breaker
with a minimum 3 mm gap between its contacts
must be installed between the power supply main
and the machine.
- Connect the electrical power cable (14) to the main
switch installed prior to the machine
- Connect the equipotential ground conductor to
the terminal (15).
• The electrical power cable can NOT be replaced
by USER but only by technical.
- The manufacturer declines all responsibility for
accidents or damage to persons or property caused
by failure to comply with the above listed provi-
sions.
