POSITION TOOLS
1. VACUUM ASSEMBLY
A. Handle
B. Vacuum Base
C. Extension Wand
D. Crevice Tool
E. Pet Turbo Tool
F. Dusting Brush
G. (1) Large Screw
H. Dirt Cup
Remove all parts from carton and identify
each item shown.
Make sure all parts are located before
disposing of packing materials.
5
1.2 1.3
1.2 Insert handle section into Vacuum Base. Push
down firmly. Using a Phillips screwdriver, fasten (1) large
screw behind handle into Vacuum Base.
1.3 Wrap hose around top of hose guide located on the
handle. Insert the hose into hose tube until you hear a click.
ATTACH DIRT CUP
1.6
1.6 Place bottom of Dirt Cup into vacuum body first.
Pivot cup into vacuum. Dirt Cup is secure when you hear a
click.
1.4 Place Crevice Tool into Extension Wand and slide into tool
storage area on left back side (C) of vacuum and place Pet
Turbo Tool on right back side (E) of vacuum as shown.
1.5 Place Dusting Brush (F) on top of Extension Wand.
CARTON CONTENTS
Actual model may vary from images shown.
ATTACH HANDLE
1.5
E
F
C
1.4
1.1
A
B C
G
H
E FD
To Next Page
